1. photocells guards
  2. cast iron frame.
  3. Time- limited two hands cut control with inhibition of successive cut.
  4. Servo-controlled computer with 10 inch touch screen highly precision cut for 0.01m/m.
  5. Foot pedal for pre-pressing to insure a better-cut accuracy.
  6. Hydraulic knife cut for high quality and powerful cut.
  7. Hydraulic press adjustable in pressure to cut: think paper, cardboard, Bristol, plastic, covers, books….
  8. Knife depth adjustable, delivered with 2 knifes
  9. Cutting line / Illuminated working surface
  10. Emergency stop button
  11. Cover on rear table
  12. Air bed main table
  13. Electromagnetic hand wheel fine tuning
  14. False clamp

Ball Bearing Screw & Linear rail
for highest precision

High precision Servo
Controlled system

Safety back gauge belt & safety
cover on rear table


Specification H660 (21") H800 (31")
A Cutting Thickness mm/inch 100 (3.93") 100 (3.93")
B Cutting Width mm/inch 660 (25.98") 800 (31.49")
C Cutting Length mm/inch 660 (25.98") 800 (31.49")
D Front Table Length mm/inch 460 (18.11) 460 (18.11)
E Table Height mm/inch 930 (36.61") 930 (36.61")
F Total Machine Length mm/inch 1,560 (61.41") 1,700 (66.92")
G Machine Width mm/inch 1,250 (49.21") 1,390 (54.72")
H Machine Height mm/inch 1,460 (57.48") 1,460 (57.48")
Electrical Supply   As required As required
Main Motor KW(HP) 2.25 (3) 2.25 (3)
Paper Feeding Motor KW(HP) 0.37 (0.5) 0.37 (0.5)
Net Weight kg 0.18 (0.25) 0.18 (0.25)
Measurement mm 900 1100

※Technical data to change without notice
