• Suitable for the precision splicing of veneers for tabletops,door skin ,and wood panels.
  • Performs splicing through edge gluing and heat curing,leaving no glue line.
  • Has a feeding speed of 20M per munute,and veneer thickness of 0.5m/mt.
  • Fully pneumatic automatic control unit does not require experienced operators.

Specification VS 0.5
Veneer Thickness mm 0.5 - 1.2
Veneer Width mm 75 - 1240
Veneer Length (minimum) mm 350
Feeding Speed m/min 10 - 25
Heating Temperature °C 100 - 200
Total Power Supply kw 4.5 (6HP)
Main Voltage   as required
Compressed Air kgs/cm2 5
Machine weight kgs 1600 ( 3520 lbs)
Overall Length mm 2250 (88.6")
Overall Width mm 2050 (80.7")
Overall Height mm 1770 (69.7")
Included tables size mm 2440 x 1220 (96" x 48")
*Technical data to change without notice
